Unbound Gravel 2026: The Ultimate Tire and Gear Setup Guide
April 15, 2026 -- 11 min read
Unbound Gravel is the defining event of the gravel racing calendar. 200 miles. Over 20,000 feet of climbing. The Flint Hills of Kansas with their relentless rolling terrain, loose limestone gravel, and brutal exposure to sun and wind.
Whether you are racing the XL or just trying to finish the MID, your tire and gearing choices will make or break your day.
The Terrain Dictates the Setup
Unbound is unique. It is not alpine climbing, and it is not flat desert gravel. The Flint Hills roll in waves: 3-8% grinds climbing out of drainage crossings, punctuated by brief punchy sections at 12-18% that catch you in the granny gear.
That combination means you need:
- Tire width: Enough volume for hours of chunky gravel (45-50mm)
- Low gear: Under 21 gear inches for 15% loose-gravel climbs
- High gear: Enough top end for paved sections and fast descents
- Reliability: Hookless-approved tires with puncture protection
What the Pros Run (2024-2025 Setups)
Pro-Level Unbound Setups:
Ted King (2025):
WTB Riddler 45c TCS Light -- SRAM Red AXS 1x -- 42t / 10-44t -- ENVE G23 hookless -- 35 PSI front / 38 PSI rear
Laurens ten Dam:
Specialized Pathfinder Pro 42mm -- 2x GRX 810 (46/30t) -- 11-40t cassette -- Roval Terra C -- 32 PSI
Top 10% Amateur (2025 XL):
Pirelli Cinturato Gravel M 45mm -- Rival AXS 1x -- 40t / 10-52t -- DT Swiss G1800 -- Dropper post -- 30 PSI w/ Stan's NoTubes
Notice the pattern? 45mm is the dominant tire width, 40-42t chainrings are standard, and 1x drivetrains have largely replaced 2x even among top finishers.
The Everyday Rider Setup (What You Should Actually Run)
Most people doing Unbound are not chasing podiums -- they want to finish. Here is the recommended setup for first-time XL riders:
Recommended First-Time Unbound XL Setup:
Tire: WTB Riddler 45c TCS Light or Schwalbe G-One RS 45mm
Drivetrain: SRAM Rival AXS 1x -- 40t / 10-52t (20.6 gear inches lowest)
Wheels: Hookless-approved, 25-30mm internal width
Pressure: 28-32 PSI (rider weight + 140-160 lbs range)
Sealant: Stan's NoTubes or Orange Seal (60ml per tire)
Extras: Dropper post (optional), chain checker, master link, CO2 kit
The 40t/52t combo gives you a 20.6 gear-inch lowest gear with 45mm tires. If you are under 140 lbs and struggle on steep climbs, consider a 38t chainring.
Tire Pressure Strategy for Unbound
Key factors: rider weight, tire width, hookless vs hooked, and course conditions. For a 160-lb rider on 45mm tires:
- Dry/fast: 30 PSI front / 32 PSI rear
- Wet/muddy: 26 PSI front / 28 PSI rear (more grip)
- Hookless rims: Stay under 50 PSI per ETRTO standards
Too high wastes watts on chunky gravel. Too low risks pinch flats on sharp limestone. Sweet spot: 28-32 PSI tubeless with quality sealant.
Need your exact PSI? The eBikePSI calculator works for any bike -- enter rider weight + bike weight + tire width for a data-driven starting point.
Hookless at Unbound: Are You OK?
Yes, as long as your tire is hookless-approved. The popular Unbound choices (WTB Riddler TCS, Pirelli Cinturato, Schwalbe G-One RS) are all hookless-safe.
The real risk is rock strikes causing bead separation on sharp limestone at speed. Set pressure high enough to avoid bottoming out, use 60ml+ sealant, and carry a spare tube and tire boot as backup.
We wrote a detailed breakdown of hookless vs hooked safety standards for the full ETRTO limits and compatibility details.
Weather Scenarios
Dry and Hot (90% of Editions)
Hydration is your enemy, not gear. Run 45mm fast-rolling tread. 30 PSI. Fresh sealant.
Wet and Muddy (2019 Edition)
Switch to 50mm tires with aggressive tread (WTB Nano 650b). Lower to 24-26 PSI for grip on slick limestone.
Wind (Always)
The exposed Flint Hills have no tree cover for 100+ miles. Bring more water than you think and use the aero benefit of a well-positioned body on hard-pack.
What NOT to Do
- Do not run an untested tire -- if it has not survived 10+ hours with sealant, do not gamble
- Do not use road gearing (50/34t) -- the climbs will punish you
- Do not skip the tubeless check -- a leaking valve or cracked rim tape will DNF you at mile 30
Bottom Line
45mm tires, 40t chainring, 10-52t cassette, hookless-approved setup, 30 PSI. This is the proven formula for first-time XL finishers. Adjust based on your local training terrain. Check your exact gearing with our calculator before committing to parts.
